When ‘s Haas automobile break up in two and burst into flames in the course of the 2020 Bahrain Grand Prix, it was the titanium halo that in the end saved his life. However what few individuals know is {that a} groundbreaking welding approach performed an important position in making the halo robust sufficient to carry out as designed in that terrifying second.
Commercial
The halo, now a vital a part of System 1’s security bundle, confronted robust opposition when it was first launched in 2018. Nonetheless, a number of high-profile crashes – together with Grosjean’s fiery accident, Zhou Guanyu’s dramatic flip at Silverstone in 2022, and the Verstappen-Hamilton conflict at Monza in 2021 – have since silenced the critics. The cockpit safety system has confirmed its price again and again.
However what not many individuals know is that manufacturing the halo to fulfill the FIA’s security requirements – to face up to the immense forces it would face, the halo needed to be able to supporting the load of a London double-decker bus – posed a serious technical problem, one which conventional manufacturing strategies could not resolve. This required not solely high-grade titanium but in addition a flawless, modern welding course of to protect the fabric’s properties.
The problem of welding titanium
By the top of 2017, the businesses that participated within the FIA’s tender for the manufacturing of the halo – together with the celebration that in the end gained the contract – didn’t have the in-house technical capabilities to weld the 5 titanium elements of the halo to the very best attainable high quality. That is after they turned to LKN WeldTitan, the titanium-specialized division of Dutch firm LKN WeldCompany BV. After almost 4 weeks of intensive analysis and growth, they succeeded in welding the elements collectively in a method that fully preserved the titanium’s technical properties, guaranteeing that the halo met FIA’s stringent requirements.
Commercial
“Titanium is a reactive steel, which suggests it reacts with components within the air – even at room temperature, in a way that oxidation happens,” explains Patrick Wouterse, founder and CEO of LKN WeldCompany, chatting with Motorsport.com. “That is why it is extremely immune to corrosion: as soon as a skinny oxide layer kinds, it protects the steel from additional oxidation, a property that makes titanium best for chemical industries.”
Patrick Wouterse, founder and CEO, LKN WeldCompany BV
Patrick Wouterse, founder and CEO, LKN WeldCompany BVLKN WeldCompany BV
LKN WeldCompany BV
However for the halo, the important thing property wasn’t simply corrosion resistance however the strength-to-weight ratio. “Titanium, particularly the grade 5 alloy used for the halo, is way stronger than metal whereas being considerably lighter,” Wouterse continues. “The place you’d want 15 millimetres of chrome steel for a sure power, you may solely want 5 millimetres of titanium. That is why it is used extensively in aerospace and why it was chosen for the halo. You need the strongest attainable construction with out including an excessive amount of weight to the automobile.”
Commercial
Nonetheless, welding titanium is a fragile course of, as heating the steel causes it to turn out to be much more reactive, making it take in components like oxygen and hydrogen “like a sponge in a bucket of water”. Even the slightest contamination, corresponding to microscopic traces of grime or oils from a fingerprint, can have already got disastrous penalties for the power of the titanium within the space the place the weld is.
“As soon as titanium absorbs these components, it adjustments the steel’s composition and weakens it dramatically, as much as 75% within the affected space,” Wouterse explains. “To stop that, it’s worthwhile to create an surroundings the place, throughout welding, no different components can attain the steel.”
The innovation: a flawless welding course of inside a purge chamber
Usually, welders defend the realm with a neighborhood stream of inert fuel, like argon, to defend the molten steel. However with titanium, that is not sufficient. “The warmth radiates outward — the encompassing materials can attain 1,000 levels Celsius. However at simply 150 levels, titanium already begins absorbing oxygen,” says Wouterse.
Commercial
“You possibly can really see the harm — the titanium adjustments color. Silver means the properties are intact, whereas gold signifies that there was a really slight however acceptable deterioration. But when it turns blue, purple, or inexperienced, the fabric is actually ruined.”
Titanium halo
Titanium haloLKN WeldCompany BV
LKN WeldCompany BV
To unravel this, Wouterse and his staff spent years perfecting a novel welding course of, constructing specialised welding purge chambers, so the welding can happen in an environment of inert fuel.
“It sounds easy – simply put the elements in a field and fill it with argon – however it’s extraordinarily advanced,” Wouterse says. The issue is that there all the time stays a small quantity of oxygen within the purge chamber. “We fill the chamber primarily with argon, helium and neon. However argon is heavy, oxygen is mild, and helium is even lighter. Even the slightest turbulence from shifting your arms contained in the gloves can combine the gases and lift oxygen ranges.”
Commercial
“We needed to discover methods to get the oxygen focus all the way down to only a few elements per million,” Wouterse continues. “All the pieces, from the form of the chamber to the wall end, impacts the consequence. In order that’s all very sophisticated. And there are no less than fifteen different variables that each one need to be good to get the best values.”
Over the previous twenty years, Wouterse has specialised on this course of. By means of LKN WeldCompany BV, he has constructed a powerful popularity, resulting in world demand for his firm’s experience in specialised welding initiatives throughout industries corresponding to aerospace, vitality, chemical, nuclear, pharmaceutical and automotive. As well as, Wouterse is often employed by corporations for course of growth and high quality management.
After FIA’s halo provider reached out to LKN by way of a mutual connection, the Amersfoort-based firm developed a customized welding chamber giant sufficient to deal with all the halo jig, taking into consideration the construction’s advanced, asymmetrical hole design. “We then certified the method in line with EN ISO requirements, welded a prototype and examined it – it simply met the FIA’s requirements,” Wouterse remembers. “After that, we moved rapidly into manufacturing. We ended up welding the primary hundred halos for System 1 in early 2018.”
Romain Grosjean, Haas F1, emerges from flames after a horrific crash on the opening lap of the Bahrain Grand Prix, Marshals attend the accident
Romain Grosjean, Haas F1, emerges from flames after a horrific crash on the opening lap of the Bahrain Grand Prix, Marshals attend the accidentAndy Hone / Motorsport Pictures
Andy Hone / Motorsport Pictures
A life-saving legacy
For Wouterse, seeing the halo in motion – particularly throughout crashes like Grosjean’s – is a supply of immense delight. “After all, you all the time hope nothing unhealthy occurs. However when it does, it is good to know there is a halo on that automobile. It makes you proud to assume, ‘We helped make that’.
Commercial
“Particularly to start with, so many individuals hated the halo — they thought it was ugly whereas a number of the drivers mentioned it obstructed their view. However after the primary huge crash the place the halo made the distinction, all of the criticism stopped. Everybody agreed it was the best factor.”
Grosjean’s crash left an enduring impression on Wouterse. “If you take a look at simulations that have been made after the incident, you see how the halo deformed the barrier simply sufficient to guard Grosjean’s head. With out it, he would not have survived. And since the halo held, he was additionally capable of climb out of the burning wreckage.”
Wouterse even exchanged messages with Grosjean afterward. “I reached out on LinkedIn and defined our position within the halo. He replied, ‘Then I suppose I have to thanks’. As an enormous System 1 fan myself, that meant rather a lot.”
Later this 12 months, Wouterse plans to go to the F1 Exhibition in Amsterdam to see Grosjean’s burned-out chassis in particular person – a robust reminder of the life-saving know-how he and his staff helped good.
